This series of mineral water filling machine are applied to the production of pure water, mineral water, with optional capacity from 3,000 to 40,000BPH. The washing, filling and capping will be finished just by this one machine.
It is very convenient to change bottle size by means of advanced bottle conveying technology-bottle neck clamping & bottle suspending technology.
Model
CGN 14-12-5
CGN 18-18-6
CGN 24-24-8
CGN 32-32-10
CGN 40-40-15
CGN 50-50-20
CGN 60-60-20
CGN 72-72-22
0.5L(Per Hour) Capacity
3000~ 4000BPH
5000~ 6000 BPH
12000 BPH
18000~ 20000 BPH
24000~26000 BPH
30000~ 33000 BPH
36000~ 38000 BPH
42000~ 40000 BPH
Bottle Suitable
PET round or square
Bottle diameter
50mm~97mm
Bottle height
150mm~320mm
Compressed air pressure
0.5~1Mpa
Washing Mdeium
Aseptic Water
Washing Water's Pressure
0.2~0.25Mpa
Total Power
4.5
4.5
5.3
7.2
10.5
13.7
13.7
16.3
Weight <kg>
3500
4000
5600
14000
16000
19000
23000
26000
Main Features: 1. Washing,filling,capping can be carried out on the same machine. The design of the machine is scientific and reasonable. 2. The water filling machine appearance is beautiful and the function is complete. The operation and maintenance is convenient. 3. The water filling machine adopts advanced technology and normal pressure filling valves, with high filling precision. The speed of filling is fast and the liquid amount is controlled accurately, with same filling level. 4. The water filling machine filling device can be stopped automatically when there is no bottle or bottles are damaged. 5. Pneumatic value and damped gears are used for bottle conveying, the noise is low and the whole machine runs smoothly. 6. The magnetic torque is used for screw capping.The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed. The caps can not be damaged, the capping is reliable.
